MDF Door Liner - FD30/FD60 Primed Door Frame Lining Set c/w Optional 10mm Trench/Grooves for Fire Intumescent Door Strips - 30 Minute Fire Rating - MDF White Painted Primed Door Liner

Download test report EN1634 FD30 MDF Door Liner

Download test report EN1634 for Intumescent strips

Universal width - kit comes with 1000mm wide header that can be cut to fit any door sizes such as 680mm, 762mm, 840mm etc. Legs are notched to support single piece header which is universal and can be cut to fit any width of door.

Note - standard is non-fired rated and comes WITHOUT trench. Hence this wont be compatible with the intumescent strips If you need a fire rated door frame, selected the FD30 TRENCHED versions. These are compatible with the intumescent strip options.

MDF Door Liner - Primed Door Frame Lining Set c/w Optional Grooves for Fire Intumescent Door Strips - FD30 30-Minute Fire Rated / Fire Check MDF White Painted Primed Door Liner

• Standard white primed MDF door liner set
• 30/60 Minute Fire Rated / Fire Check Version c/w 10mm Trench / Grooved for intumescent strips (sold separately)
• Full door liner set complete with 2 Legs @ 2100mm, 1 Head at 1000mm
• Supplied complete with 32mm x 12mm (or 25mm jamb for FD30 fire rated model) Door stops (door jamb strips / slamming strips)
• Choice of 95mm, 108mm, 131mm, 150mm wide - door liner is 27mm thick
• Moisture-resistant MDF with a density 620kgM3 for for the standard door frames & 720kgM3for the FD30 Models, the linings are produced defect-free - no knots and no warps
• Pre-cut trench (the notched part of the legs where the head slots in) 15mm from edge of legs, can be adjusted but cutting the legs down accordingly
• Primed - 2 coats of white-primer applied - ready for directly undercoating / top coating reducing the installation cost and time
• Head can be cut down to fit a number of door sizes from common sizes such as 686mm, 762mm, 840mm, 926mm up to a maximum door size of 980mm  wide x 2040mm high
• Choose between standalone door frame lining set or FD30 fire door liner set with 10mm wide x 4mm deep to accomodate fire door intumescent strips (sold separately)

Download test report EN1634 FD30 MDF Door Liner

Download test report EN1634 for Intumescent strips
